SC Tables
D117/D118 6-20 SM
6.1.6 SC4XX: IMAGE PROCESSING - 2
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
442 D
Image transfer belt contact motor error
The image transfer belt contact motor drives beyond the specified time
during home position detection or contact operation.
 Broken harness or defective connectors
 Disconnected connector of image transfer belt contact sensor or
motor
 Defective image transfer belt contact motor
 Image transfer belt unit not installed
1. Check and replace the harness and connectors.
2. Replace the image transfer belt contact motor.
3. Reinstall the image transfer belt unit.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
452 D
Paper transfer belt contact motor error
The paper transfer belt contact motor drives beyond the specified time
during home position detection or contact operation.
 Broken harness or defective connectors
 Disconnected connector of paper transfer belt contact sensor or
motor
 Defective paper transfer belt contact motor
 Paper transfer belt unit not installed
1. Check and replace the harness and connectors.
2. Replace the paper transfer belt contact motor.
3. Reinstall the paper transfer belt unit.
