2.14 CONTROLLER OPTIONS
2.14.1 OVERVIEW
 Always touch a grounded surface to discharge static electricity from your hands before
you handle SD cards, printed circuit boards, or memory boards.
This machine has I/F card slots for optional I/F connections and SD card slots applications.
After you install an option, check that the machine can recognize it (see "Check All Connections"
at the end of this section).
I/F Card Slots
 Slot [A] is used for one of the optional I/F connections (only one can be installed): IEEE1284,
IEEE802.11a/g, g (Wireless LAN), File Format Converter and Gigabit Ethernet board.
SD Card Slots
 Slot 1 (upper) is used for optional applications (e.g., Browser Unit, VM Card, PictBridge etc).
 Slot 2 (lower) is used for service only (for example, updating the firmware).
