SP Mode
Tables
5840 [IEEE 802.11]
006
Channel Max DFU *CTL
[1 to 11 or 13 / 11 or 13 / 1/step]
Range(Default)
Europe/Asia: 1 to 13 (13)
NA/ Asia: 1 to 11 (11)
Sets the maximum number of channels available for data transmission via the
wireless
LAN. The number of channels available varies according to location. The
default settings are set for the maximum end of the range for each area.
Adjust the upper 4 bits to set the maximum number of channels.
 Do not change the setting.
007
Channel Min DFU *CTL
[1 to 11 or 13 / 1 / 1/step]
Range
Europe: 1 to 13
NA/ Asia: 1 to 11
Sets the minimum number of channels available for data transmission via the
wireless LAN. The number of channels available varies according to location.
The default settings are set for the minimum end of the range for each area.
Adjust the lower 4 bits to set the minimum number of channels.
 Do not change the setting.
