Main SP Tables-5
D117/D118 3-362 SM Appendix
008 Transmission Speed *CTL
[0x00 to 0xFF / 0xFF to Auto / -]
0 x FF to Auto [Default]
0 x 11 - 55M Fix
0 x 10 - 48M Fix
0 x 0F - 36M Fix
0 x 0E - 18M Fix
0 x 0D - 12M Fix
0 x 0B - 9M Fix
0 x 0A - 6M Fix
0 x 07 - 11M Fix
0 x 05 - 5.5M Fix
0 x 08 - 1M Fix
0 x 13 - 0 x FE (reserved)
0 x 12 - 72M (reserved)
0 x 09 - 22M (reserved)
011
WEP key Select *CTL
[00 to 11 / 00 / 1 binary/step]
00: Key #1
01: Key #2 (Reserved)
10: Key #3 (Reserved)
11: Key #4 (Reserved)
Selects the WEP key.
013
RTS/CTS Thresh *CTL [0 to 3000 / 2432 / 1/step]
Adjusts the RTS/CTS threshold for the IEEE802.11 card.
This SP is displayed only when the IEEE802.11 card is installed.
042
Fragment Thresh *CTL [256 to 2346 / 2346 / 1/step]
Adjusts the fragment threshold for the IEEE802.11 card.
This SP is displayed only when the IEEE802.11 card is installed.
