Anti-condensation Heater (Optional Unit)
SM 2-69 D117/D118
Installation
No. Description Q’ty
6
Joint bracket (Front center) (only for
the optional paper feed unit)
1
7 Joint bracket (Rear) 4
8
Joint bracket (Frame) (only for optional
paper feed unit)
1
9 M3 x 6: Screw 11
10 M3 x 12: Screw 1
11 Tapping screw 3
2.12.2 INSTALLATION PROCEDURE
 Unplug the machine power cord before starting the following procedure.
 Do the following procedure not to damage any harnesses.
 Check that harnesses are not damaged or pinched after installation.
