IP-FAX Specifications
SM 149 D649
Fax Option
Type C305
(D649)
4.8 IP-FAX SPECIFICATIONS
Network:
Local Area Network
Ethernet/10base-T, 100base-TX
IEEE802.11a/g (wireless LAN), 1000 Base-T
Scan line density:
8 x 3.85 lines/mm, 200x100dpi (standard character),
8 x 7.7lines/mm, 200x200dpi (detail character),
Original size: A4
Maximum scanning
size:
A4, 216 x 356 mm, Irregular, 216 x 1200 mm
Transmission
protocol:
Recommendation: T.38, TCP, UDP/IP communication, SIP (RFC
3261 compliant), H.323 v2
Compatible
machines:
IP-Fax compatible machines
IP-Fax transmission
function:
Specify IP address and send fax to an IP-Fax compatible fax
through a network.
Also capable of sending fax from a G3 fax connected to the
public telephone lines via a VoIP gateway.
IP-Fax reception
function:
Receive a fax sent from an IP-Fax compatible fax through a
network.
Also capable of receiving fax from a G3 fax connected the public
telephone lines via a VoIP gateway.
