Bit Switches
SM 69 D649
Fax Option
Type C305
(D649)
System Switch 10 (SP No. 1-101-017)
No Function Comments
0-7
Threshold memory level for
parallel memory transmission
Threshold = N x 128 KB + 256 KB
N can be between 00 - FF(H)
Default setting: 02(H) = 512 KB
System Switch 11 (SP No. 1-101-018)
No Function Comments
0
TTI printing position
0: Superimposed on the page
data
1: Printed before the data
leading edge
Change this bit to 1 if the TTI overprints
information that the customer considers to be
important (G3 transmissions).
NOTE: If "1" is selected, it is possible that sent
data is printed on two sheets of paper.
1-2 Not used Do not change the factory settings.
3
TTI used for broadcasting
0: The TTIs selected for each
Quick/Speed dial are used
1: The same TTI is used for all
destinations
1: The TTI (TTI_1 or TTI_2) which is selected
for all destinations during broadcasting.
4-7 Not used Do not change the factory settings.
