Bit Switches
D649 110 SM
G3 Switch 0A (SP No. 1-105-011)
No Function Comments
0-1
Maximum allowable carrier drop
during image data reception
These bits set the acceptable modem
carrier drop time.
Try a longer setting if error code 0-22 is
frequent.
Bit 1 Bit 0 Value (ms)
0 0 200
0 1 400
1 0 800
1 1 Not used
2
Select cancellation of high-speed RX
if carrier signal lost while receiving
0: Off
1: On
This switch setting determines if
high-speed receiving ends if the carrier
signal is lost when receiving during
non-ECM mode
3 Not used Do not change the settings
4
Maximum allowable frame interval
during image data reception.
0: 5 s 1: 13 s
This bit set the maximum interval
between EOL (end-of-line) signals and
the maximum interval between ECM
frames from the other end.
Try using a longer setting if error code
0-21 is frequent.
5 Not used Do not change the settings.
