No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
1. Remove the heat seal from each PCDU.
2. Replace the defective PCDU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
396 D Drum/Development motor error: Bk
397 D Drum/Development motor error: Cy, Ma, Ye
- -
The machine detects a High signal from the drum/development motor
for 2 seconds after the drum/development motor turned on.
 Overload on the drum/development motor
 Defective drum/development motor
 Defective harness
 Shorted 24 V fuse on the PSU
 Defective interlock system
1. Check or replace the harness.
2. Replace the drum/development motor.
3. Replace the 24V fuse on the PSU.
