Anti-condensation Heater (Optional Unit)
D117/D118 2-78 SM
4. Join the two paper feed units with two joint brackets (rear) [A] and one screw [B] (M3 x 6: x
3 (included in this kit)).
5. Reassemble the mainframe and the paper feed units.
 When installing the mainframe with two paper feed units, join the two paper feed units
first, and then join the mainframe with the paper feed units. However, if there is already a
machine with one optional paper feed unit, you can put a machine with a paper feed unit
on another paper feed unit, and join them (be careful if you do this, because the
mainframe with one paper feed unit is very heavy).
