ng
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
230
-01
D FGATE ON error: Bk
-02 D FGATE ON error: Cy
-03 D FGATE ON error: Ma
-04 D FGATE ON error: Ye
The PFGATE ON signal does not assert within 5 seconds after
processing start timing for black (-01), cyan (-02), magenta (-03) or
yellow (-04) color writing.
 Defective ASIC (Lupus)
 Poor connection between controller and BICU
 Defective BICU
1. Check the connection between the controller board and the BICU.
2. Replace the BICU.
3. Replace the controller board.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
231
-01
D FGATE OFF error: Bk
-02 D FGATE OFF error: Cy
-03 D FGATE OFF error: Ma
-04 D FGATE OFF error: Ye
 The PFGATE ON signal still asserts within 5 seconds after
processing finish timing for black (-01), cyan (-02), magenta (-03)
or yellow (-04) color writing.
 The PFGATE ON signal still asserts when the next job starts.
See SC 230 for troubleshooting details.
