SC Tables
D117/D118 6-40 SM
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
1. Install the expanded authentication module.
2. Install the SD card.
3. Set the following super service SPs and turn the main switch off and
on.
1. User limitation: Set SP5401-160 (expanded authentication
management setting) to 0.
2. User limitation: Set SP5401-161 (expanded authentication
management detailed setting) to 0.
5. Execute SP5-876-1 (security all clear). If this is a mass-produced
machine,
Replace the NVRAM on the controller board.
-02 D
Version error
The version of the expanded authentication module is not correct.
 Incorrect module version
Install the correct file of the expanded authentication module.
-11 D
OSM user code file error
The correct "usercode" file could not be found in the root folder of the
SD card because the file is not present, or the existing file is corrupted
or the wrong type file.
1. Create the usercode files with the User Setting Tool "IDissuer.exe"
and store the files in the root folder of the SD card.
Note:
Make sure the eccm.mod file is in the root folder of the SD card.
To Next Page
