Maintenance Tables
D117/D118 2-2 SM Appendix
Item 45K 60K 90K 120K 240K EM Remarks
Paper Transfer Roller
Unit
(R)
Fusing
Fusing Unit (R)
Paper Path
Registration Roller C Damp cloth
Registration Sensor C
Blower brush or
dry cloth
Inverter Roller C Damp cloth
Paper Dust Case C Blower brush
Paper Feed Roller (R) C Damp cloth
Paper Feed Exit Sensor C
Blower brush or
dry cloth
By-pass Feed Roller (R) C Damp cloth
Separation Pad (R) C Dry cloth
Paper Path (Duplex)
Duplex Entrance Sensor C
Blower brush or
dry cloth
Duplex Exit Sensor C
Blower brush or
dry cloth
Duplex Rollers C Damp cloth
Duplex Entrance Guide
Plate
C
Damp cloth;
alcohol
ARDF
ADF Separation Pad C Dry cloth
Pick-up Roller C Damp cloth
To Next Page
