Main SP Tables-2
D117/D118 3-88 SM Appendix
Displays the values for each correction.
"M. Cor.: Dot" indicates the dot correction value in the main scan direction.
"M. Cor.: Subdot" indicates the sub dot correction value in the main scan
direction.
"S. Cor.: Dot" indicates the dot correction value in the sub scan direction.
"S. Cor.: Subdot" indicates the sub dot correction value in the sub scan
direction.
003 Skew: M *ENG
[-5000.000 to 5000.000 / - /
0.001um/step]
011 M. Cor.: Dot: M *ENG [-512 to 511 / - / 1dot/step]
012 M. Cor.: Subdot: M *ENG [-1.00 to 1.00 / - / 0.01dot/step]
015 M. Left Mag.: Subdot: M *ENG [-32.00 to 32.00 / - / 0.01dot/step]
016 M. Right Mag.: Subdot: M *ENG [-32.00 to 32.00 / - / 0.01dot/step]
017 S. Cor.: 600 Line: M *ENG [-16384 to 16383 / - / 1line/step]
018 S. Cor.: 600 Sub: M *ENG [-1.000 to 1.000 / - / 0.001line/step]
019 S. Cor.: 1200 Line: M *ENG [-16384 to 16383 / - / 1line/step]
020 S. Cor.: 1200 Sub: M *ENG [-1.000 to 1.000 / - / 0.001line/step]
021 Skew: C *ENG
[-5000.000 to 5000.000 / - /
0.001um/step]
029 M. Cor.: Dot: C *ENG [-512 to 511 / - / 1dot/step]
030 M. Cor.: Subdot: C *ENG [-1.00 to 1.00 / - / 0.01dot/step]
033 C. Left Mag.: Subdot: M *ENG [-32.00 to 32.00 / - / 0.01dot/step]
034 C. Right Mag.: Subdot: M *ENG [-32.00 to 32.00 / - / 0.01dot/step]
035 S. Cor.: 600 Line: C *ENG [-16384 to 16383 / - / 1line/step]
036 S. Cor.: 600 Sub: C *ENG [-1.000 to 1.000 / - / 0.001line/step]
037 S. Cor.: 1200 Line: C *ENG [-16384 to 16383 / - / 1line/step]
038 S. Cor.: 1200 Sub: C *ENG [-1.000 to 1.000 / - / 0.001line/step]
