Main SP Tables-2
D117/D118 3-176 SM Appendix
2661
[Thick2:Bias]
Adjusts the DC voltage of the discharge plate for thick2 paper.
003 Separation DC:1side *ENG
[0 to 4000 / 2000 / 10-V/step]
004 Separation DC:2side *ENG
2663
[Thick2:Bias:BW
Adjusts the current for the paper transfer roller for thick 2 paper in
black-and-white mode.
003 PaperTransfer:1side *ENG [0 to 200 / 8 / 1-uA/step]
004 PaperTransfer:2side *ENG [0 to 200 / 11 / 1-uA/step]
2667
[Thick2:Bias:FC]
Adjusts the current for the paper transfer roller for thick 2 paper in full color
mode.
003 PaperTransfer:1side *ENG [0 to 200 / 11 / 1-uA/step]
004 PaperTransfer:2side *ENG [0 to 200 / 17 / 1-uA/step]
