SP Mode
Tables
3461 [TonerSupply :DANC]
001 PI:Power *ENG
Changes the request values of PI at one
time.
[5 to 200 / 100 / 1%/step]
011 PI:I Gain *ENG
Sets I gain.
[0.00000 to 0.10000 / 0.01000 /
0.00001/step]
012 PI:P Gain *ENG
Sets P gain.
[0.00000 to 1.00000 / 0.01000 /
0.00001/step]
021 PI:I Limits:Up *ENG Sets the limit for the I or P request value
(supply plus side).
[0.00 to 1.00 / 0.10 / 0.01/step]
022 PI:P Limits:Up *ENG
023 PI:I Limits:Low *ENG
Sets the limit for the I request value
(supply minus side).
[0.00 to 1.00 / 0.20 / 0.01/step]
024 PI:P Limits:Low *ENG [0.00 to 1.00 / 0.10 / 0.01/step]
031 AW:AWIlow *ENG
Sets AW gain.
[0 to 1000 / 1000 / 1/step]
033 AW:AWIpni *ENG
103 PI:SpdCoef:LowSpd *ENG [0.01 to 1.00 / 0.50 / 0.01/step]
111 SMITH:Gain *ENG
Sets the gain for the Smith model.
[0.00 to 2.00 / 1.00 / 0.01/step]
113 SMITH:LowSpd *ENG
Sets the liner speed correction to the gain
for the Smith model.
[0.00 to 1.00 / 1.00 / 0.01/step]
