Vision Operator’s Manual (v12.0 MD) Picture Frame Borders • Ops 14–7
•Use the Blue knob on the S&T MD Border Color Menu to adjust the amount of
blue that is being mixed (0.0% has no intensity, and 100.0% has full intensity).
9. Adjust colors using the HSL color mode as follows:
•Use the Luminance knob on the S&T MD Border Color Menu to adjust the
luminance of the border. The luminance can be adjusted from 0.0% (minimum
brightness) to 100.0% (maximum brightness). The bar to the right of the color
wheel shows the level of luminance.
•Use the Saturation knob on the S&T MD Border Color Menu to adjust the color
saturation of the border. Saturation can be adjust from 0.0% (monochrome or no
saturation), to 100.0% (full color saturation).
•Use the Hue knob on the S&T MD Border Color Menu to adjust the color of the
border. A full 360° of hue adjust is provided.
Operating Tip — Pressing the Default Color button resets the RGB and HSL levels to the
default levels. You cannot default the levels if you are controlling multiple Flying Keys with
different border styles.
This completes the procedure for adjusting the color of the border.
