A.4
SEL-751A Relay Instruction Manual Date Code 20100129
Firmware and Manual Versions
Instruction Manual
IEC 61850 and
ACSELERATOR Architect
Versions
Newer SEL-751A firmware (R102 and higher) uses a different software
library from earlier versions and is unable to process version 001 CID files.
ACSELERATOR
®
Architect
™
SEL-5032 Software generates CID files from
ICD files, so the ICD file version number and CID file version number are the
same. If downloaded to the SEL-751A, an incompatible CID file will generate
file parse errors during processing and disable the IEC 61850 protocol.
If you perform an SEL-751A firmware upgrade that spans different file
version compatibilities, the relay may be unable to process the stored CID file.
See the SEL-751A firmware upgrade instructions for CID file conversion
procedures.
See Table A.5 for compatibilities between
ACSELERATOR Architect, ICD/CID
files, and SEL-751A firmware versions.
Instruction Manual
The date code at the bottom of each page of this manual reflects the creation
or revision date.
Table A.6 lists the instruction manual release dates and a description of
modifications. The most recent instruction manual revisions are listed at the
top.
SEL-751A-R102-V0-Z002001-D20080121 ➤ Corrected 51N pickup setting for relays with different nom-
inal ratings for their phase and neutral inputs.
20080121
➤ Removed solid-state outputs option and added fast hybrid
(high-speed, high-current interrupting) outputs option.
➤ Enhanced IEC 61850 functionality with KEMA certifica-
tion updates.
SEL-751A-R101-V0-Z002001-D20070806
➤ Internal changes to support new hardware (current and volt-
age cards).
20070806
➤ Revised for Port 2 as an optional fiber-optic serial port.
➤ Added de-bounce settings for digital inputs.
SEL-751A-R100-V0-Z001001-D20070410 This original firmware version was not production released. 20070410
Table A.4 100 Series Firmware Revision History (Sheet 2 of 2)
Firmware Identification (FID) Number Summary of Revisions Manual Date Code
Ta b le A .5 ACSELERATOR Architect CID File Compatibility
ACSELERATOR Architect
Software Version
ACSELERATOR Architect
ICD/CID File Version
SEL-751A Firmware
All versions Ver 001 R101
R.1.1.69.0 or later Ver 002/002L R102 or later
R.1.1.80.0 or later Ver 002 R200
Ver 002 R300
R200 or later
R300 or later
