Page #104 background image
Engineering via SICAM TOOLBOX II
104 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
4.1 Telecontrol
Overview of the Tasks
Task Meaning
Presets Define user and rights
Initialization of the plant data Configure plant and automation unit
Import firmware Load firmware into the SICAM TOOLBOX II
HW configuration Selection of the installed system elements
Parameterization of the sys-
tem technique
Time management
Communication common
Protocol elements
Assignment of process signals to data points
Decentral archive
Parameterization of the pro-
cess technique
Create images
Assign images to data points
Settings for configured process signals
Routing of send data and receive data
Bulk edit Creation of great amounts of values of the images
Transfer parameters Compile the set values
SD card Write and read application data
Import/Export Restore and backup of application data
Documentation Prepared spreadsheets for printing
Hardware (configuration, pin assignment)
Parameters
Load parameters Transfer parameters and function diagram to the target device
Parameter comparison Compare settings between current project and target device
Dataflow test Record and store dataflow in the target device
Message simulation Send messages from the SICAM TOOLBOX II to a target de-
vice
Service function online Read and set time of target device
ST emulation Execute system-internal functions (only for authorized users)
Topology test Acqusition of physically connected automation units in a
SICAM RTUs automation network
Diagnosis Read detailed information generated by the self monitoring
Read decentral archive Chronological display of parameterized events
