Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 159
DC8-001-2.09, Edition 08.2016
5.1.7.2 Physical Interface for the Communication
SICAM CMIC can communicate simultaneously via up to 4 physical interfaces. For each con-
figured protocol element an interface must be assigned exclusively.
The assignment of the interface for each protocol element resides in the directory tree under
SICAM CMIC | Master module | PRE <0…3>: <protocol name> | Common settings.
With the parameter Interface the following assignments are possible:
Protocol Designation Interface
X1
LAN
X2
RS-232
X3
RS-485
X4
LAN
103MT0 Protection Master -
ü ü
-
BPPT0 End-end traffic -
ü ü
-
DIAST0 Dial-up traffic Slave -
ü
- -
ET83 Ethernet TCP/IP (IEC 61850 Ed.1)
ü
*)
- -
ü
*)
ET84 Ethernet TCP/IP (IEC 60870-5-104)
ü
*)
- -
ü
*)
ET85 Ethernet TCP/IP (IEC 61850 Ed.2)
ü
*)
- -
ü
*)
UMPMT0 Multi-point traffic Master -
ü ü
-
UMPST0 Multi-point traffic Slave -
ü ü
-
AGPMT0 AGP interfacing Master -
ü ü
-
BMCUT0 Benning MCU ASCII protocol -
ü ü
-
COUMT0 Counter interfacing Master -
ü ü
-
DNPST0 DNP3 Slave -
ü ü
-
DNPiT1 DNP3 TCP/IP Slave
ü
*)
- -
ü
*)
MODMT0 Gould Modbus Master -
ü ü
-
MODST0 Gould Modbus Slave -
ü ü
-
MODMT2 Gould Modbus Master -
ü ü
-
PCBST0 SAT SK 1703 PCMBA GV-S 2) -
ü ü
-
RP5UT1 ABB RP570/571 GV-U -
ü ü
-
SMST0 ASCII protocol for SMS alerting -
ü
- -
ST1ST0 Siemens SIMATIC S5 ST1 GV-S -
ü ü
-
TG8ST0 L&G Telegyr 800 GV-S -
ü ü
-
*)
no selection possible, fixed assigned to LAN
