Page #93 background imageLoading...
Page #93 background image
Preparing the Engineering
SICAM RTUs, User Manual SICAM CMIC 93
DC8-001-2.09, Edition 08.2016
3.8.2.3 Parameter Entry
In the submenu Settings you find all configuration data of the device. The equipment can be
made here as well.
You have the possibility to change configuration parameters. In the left window area, all con-
figuration data is shown as a hierarchical directory tree:
SICAM CMIC
Master Module
Note
At present, a modification of periphery parameters (node I/O Master Module) is not possible.
At present, navigation is possible via mouse only (via finger in case of touch screen).
In order to carry out modifications, you have to log in as administrator.
This is how to retrieve information about parameters:
In the directory tree, select any node
You can expand or collapse each directory by clicking or
To the right of the directory tree, all parameters of the selected parameter group or table pa-
rameters (such as topology information, dataflow messages and so on) are shown in a table.
Select the parameter group or parameter you want
In the table, click on a value of a parameter
For showing/hiding the description of the selected parameter, click on the yellow bar locat-
ed to the right of the work area
