Siemens SICAM CMIC - LAN;WAN Connection Via Serial Interface and Terminalserver

Preparing the Engineering
SICAM RTUs, User Manual SICAM CMIC 77
DC8-001-2.09, Edition 08.2016
3.7.1.1.4 LAN/WAN Connection via Serial Interface and Terminalserver
PC and target device are connected via a network and a terminalserver (DSUB9 connector).
TOOLBOX II
Revision:
License Pak:
Version 5 | Siemens AG
F4
F3
F2
F1
POK
RY
ER
ETH
LK1
PK1
RS-2 32
OH2
RS-4 85
OH3
ETH
LK4
PK4
SD
X4
Ethernet TCP/IP 60870-5-104
SICAM TOOLBOX II
SICAM CMIC
Terminal
Server
Direct cable
Standard patch cable
