Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 249
DC8-001-2.09, Edition 08.2016
5.2.2.1.1 Import Application Program
For the execution of the open-/closed-loop control function the corresponding IL must be loaded
on the target device.
This is how to upload an IL to the target device:
Click on the button , if an IL is available in ASCII format
You have the possibility to abort the procedure.
Click Select a file to open the selection dialog
Select the source directory and the source file (the file type must be .plc)
Click on the button in order to start the import
The target device starts the loading procedure. The duration of the loading procedure de-
pends on the program size and the used communication connection.
Note
During the generation procedure the menu must not be left. The selection of another webpage may lead to
the occurrence of undefined states.
The program file is checked upon validity. If the data is invalid, an error indication is displayed.
If the data is valid, the following dialog appears:
Click on the button
