Preparing the Engineering
70 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
3.4 Integrated Protocol SNMP
SICAM CMIC supports the protocol SNMP Agent (version 2 and version 3). For the engineer-
ing of the SNMP protocol you need to get MIB files and a MIB browser.
3.4.1 Download of the SICAM CMIC MIB-Files
MIB-files can be downloaded from the website http://www.siemens.com/sicam:
• Select > Home > Products, Systems & Solutions > Substation Automation > Substa-
tion Control Systems and Remote Terminal Units
• Click on Downloads and open SICAM CMIC | Manuals
• In the result list click on SICAM RTUs SNMP MIB File in order to start the download
After the download you get the file SICAMRTUs_SNMP_MIB_V02.00.00.zip.
• Save this file on the computer where the MIB-browser is installed
• Open the file and start the therein contained file by means of double-click:
SICAMRTUs_SNMP_MIB_V02.00.00.exe
The MIB files are automatically stored on your computer. You find them in the subdirectory
C:/siemens/SICAMRTUS_SNMB_MIB_V02.00.00/MIB-Files.
3.4.2 Import of the MIB-Files in MIB-Browser
The import of the MIB-files into your MIB-browser must be done in the following sequence:
1. Import of SIEMENS-SMI.mib
2. Import of sicamRTUs.mib
3. Import of RFC1213-MIB (optional)
4. Import of rfc3635_mib.mib (optional)
5. Import of rfc2790_mib.mib (optional)
Besides a standard MIB-browser you can load the MIB files also with the following Siemens
products:
• SICAM 230
• 250 SCALA
