Engineering via SICAM WEB
186 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
5.1.9.4 Assigning Signals to the I/O Module
If you have already defined signals, these can be assigned to the I/O modules.
This is how to assign signals to the peripheral element:
• Click on the button right above in order to close the work area for the signal genera-
tion
• Select the directory SICAM CMIC | Master Module | I/O Master Module | <0…7>: <mod-
ule name>
• Mark on the right side the signals to be assigned
• Click on the button (Assign)
The assigned signals are now listed in a table under the tab Assignment.
