SICAM RTUs, User Manual SICAM CMIC 395
DC8-001-2.09, Edition 08.2016
F Use Cases
Contents
F.1 SICAM CMIC as Telecontrol Substation ....................................................... 396
F.2 SICAM CMIC as Telecontrol Substation with Node Function (Protocol
Converter) .................................................................................................... 397
F.3 SICAM CMIC as Telecontrol Substation with Integrated Switch for External
System Connection ...................................................................................... 398
F.4 SICAM CMIC as Telecontrol Substation with Integrated Switch for SICAM
TOOLBOX II Connection .............................................................................. 399
F.5 SICAM CMIC with IPSec VPN ...................................................................... 400
This chapter shows the network structure of typical SICAM CMIC applications.
Note
The IP addresses and subnet maks shown in these examples are exemplary and serve only for better un-
derstanding. These must be adopted according to your application.
