Engineering via SICAM WEB
182 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
5.1.9.3 Assigning Signals to the Peripheral Element (I/O Master Module)
If you have already defined signals, these can be assigned to the peripheral element for the
further processing.
This is how to assign signals to the peripheral element:
• Click on the button right above in order to close the work area for the signal genera-
tion
• Select the directory SICAM CMIC | Master Module | I/O Master Module
• Mark on the right side the signals to be assigned
• Click on the button (Assign)
The assigned signals are now listed in a table under the tab Assignment.
