Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
224 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
5.1.10.1.1 Supported Signal Types
Processing type Type identification
Signal inputs
DI_SI Single-point information (TI 30)
DI_DI Double-point information (TI 31)
DI_CV Counter value (TI 37)
DI_CV_Sub Counter value (TI 37)
AI_I Measured value normalized (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
AI_U Measured value normalized (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
AI_T Measured value normalized (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
T_AI_I (CTVT) Measured value normalized (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
T_AI_U (CTVT) Measured value normalized (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
Signal outputs
DO_SI Single-point information (TI 30)
DO_SX Single-point information (TI 30)
Single command (TI 45)
DO_DX Single command (TI 45)
Double command (TI 46)
DO_SC_1POL Single command (TI 45)
DO_SC_1,5POL Single command (TI 45)
DO_SC_2POL Single command (TI 45)
DO_DC_1POL Single command (TI 45)
Double command (TI 46)
Tap positioning command (TI 47)
DO_DC_1,5POL Single command (TI 45)
Double command (TI 46)
Tap positioning command (TI 47)
DO_DC_2POL Single command (TI 45)
Double command (TI 46)
Tap positioning command (TI 47)
AO_I Measured value normed (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
Setpoint normed (TI 48)
Setpoint scaled (TI 49)
Setpoint short floating point (TI 50)
AO_U Measured value normed (TI 34)
Measured value scaled (TI 35)
Measured value short floating point (TI 36)
Setpoint normed (TI 48)
Setpoint scaled (TI 49)
Setpoint short floating point (TI 50)
