Preparing the Engineering
SICAM RTUs, User Manual SICAM CMIC 97
DC8-001-2.09, Edition 08.2016
This is how to select all rows:
• Place a checkmark in front of the table name in the table header to place a checkmark in
front of each row:
This is how to save your modifications:
• To conclude save your changes, refer to Apply
A restart with subsequent startup of the target device may be necessary after saving, refer to
Restart device.
Note
The storage of values is possible only with equipped SD card.
This is how to undo your modifications since the last saving procedure:
• Click on the symbol (refer to Reload)
• Close your browser without saving, if you want to finish your work
3.8.2.3.1 Show Expert Parameters
For the most applications not all of the available parameters are required. For special cases,
additional parameters are provided (expert parameters).
To simplify the engineering of the target device, the expert parameters are hidden by default.
Thereby the directory tree has a reduced number of directories and parameter tables have a
reduced number of columns (no impact on the parameter table of the signals page).
When activating the checkbox Show all parameters the expert parameters get visible:
The state of the checkbox is maintained during the current session. When logging on again,
the state of the checkbox is deactivated.
