Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 189
DC8-001-2.09, Edition 08.2016
5.1.9.4.1 Automatic Display of Signal States
Process signals that are acquired or output via HW pins are automatically configured for the
process display via SICAM WEB and for the process display on the LCD.
The automatic process display resides in SICAM WEB in the menu I/O Modules (see
5.1.10.2, Display Process Values).
The automatic process display resides on the LCD in the menu Monitoring | I/O Modules
(see 6.1.2.4.6, I/O Modules).
5.1.9.4.2 Parameters with Assignment on the DI Module
Processing type Parameter Meaning
DI_DI – double-point in-
formation input
Inversion_0 Inversion (S)
NO/YES
Flutt_dp_qds Datapoint quality discriptor for fluttery binary
information
BL/IV
Inversion_1 Inversion (S)
NO/YES
block Blocking (=not used) (S)
NO/YES
SVM_monitoring Power monitoring. The sensor voltage is moni-
tored by an own power monitoring input (S).
NO/YES
Flutt_Number Number of transients for flutter suppression
(S)
SW_Filter_t Software filter-time in s (S)
Flutt_t Flutter time in seconds.
0 = no fluttersuppression (S)
0.1 to 6553.5
int_posit_t Intermediate position suppression time in se-
conds.
0 = no intermediate position suppression (S)
faulty_pos_t Faulty position suppression time in seconds.
0 = no faulty position suppression (S)
AR_sign_t Time for signalling the automatic reclosure in
seconds 0=no signalling of autom. reclosure
(S)
0.1 to 25.5
ON_before_OFF Definition of the order for the wiring of double
commands/double point information NO: OFF
is I/O with lower I/O number ON is I/O with
higher I/O number YES: ON is I/O with lower
I/O number OFF is I/O with higher I/O number
NO/YES
Moduleselection_SVM_
monitoring
Switch for power monitoring handling (PM)
Standard PM (PM inputs per modules) or input
IN D17 of one BI-module as PM input for all
modules Attention: Selected module must be
a DI module.
Flutt_t_stable Flutter suppression: stability time in seconds.
0 = stability time defined through parameter
Flutt_t (S)
0.1 to 6553.5
