Siemens SICAM CMIC User Manual

Preparing the Engineering
80 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
3.7.2.1.2 Point-to-Point Connection via Ethernet Interface
The parameterization via point-to-point is suitable if the engineering PC and SICAM CMIC are
not operated in a network.
PC and target device are connected with a cross connected patch cable via the Ethernet inter-
face (RJ45 connector).
3.7.2.1.3 LAN/WAN Connection via Ethernet Interface
The parameterization via LAN/WAN is suitable if the engineering PC and (several)
SICAM CMIC are operated in a network.
PC and target device are connected with a network via a standard patch cable (RJ45 con-
nector).
SI C A M C MI C
F4F3F2F1
SI C A M C MI C
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RTX2
RS-485
OH3
RTX3
ETH
LK4
PK4
SD
X4
SICAM CMIC
Twisted pair EN twisted pair
cable CAT5 (T41-258--)
Web browser
SICAM CMIC
F4F3F2F1
SI C A M C MI C
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RTX2
RS-485
OH3
RTX3
ETH
LK4
PK4
SD
X4
SICAM CMIC
Ethernet TCP/IP 60870-5-104
Standard patch cable
Web browser
