Installation
40 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
1.4.1.6 GPRS
Order information for the transmission facility and cables see SICAM CMIC System Descrip-
tion, Appendix “Order Information“, section “Accessories“.
1.4.2 Ethernet Communication (LAN/WAN)
Note
Depending whether a connection is done inside or outside of cabinets, differenttypes of patch cables must
be used.
You can find details on connections above 10 m in the manual SICAM RTUs Platforms Con-
figuration Automation Units and Automation Networks, appendix A; section "Electrical Con-
nection, Cable longer than 10 m".
F4
F3
F2
F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
GPRS Modem
Patch cable
F4F3F2F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
Ethernet TCP/IP
IEC 60870-5-104
Switch
Patch cable
