Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
204 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
5.1.9.4.4 Parameters with Assignment on the AI Module
Processing type Parameter Meaning
AI_I – current value
acqisition
line frequency The noise rejection takes place for the
parametrized line frequency
• 50 Hz
• 60 Hz
• 16.7 Hz
Zero range Zero range suppression (and check of the
plausibility limits) (S)
NO/YES
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
block Blocking (=not used) (S)
NO/YES
Processing grid Processing grid in seconds
0.1 to 25.5
X_0% Nominal range in the physical unit of the in-
put/output (0%) (S)
-50.0 to 50.0
X_100% Nominal range in the physical unit of the in-
put/output (100%)
-50.0 to 50.0
Y_0% Technological or normalized value 0% (S)
-1000000000000000.000 to
1000000000000000.000
Y_100% Technological or normalized value 100% (S)
-1000000000000000.000 to
1000000000000000.000
Smoothing 0 - 99 in %. 0% = no smoothing, 99% = high-
est possible smoothing
0 to 99
MV_conv_free_Xl Limit of not plausible range. Parameter is only
effective, if the parameter ze-
ro_range_a_MV_conv is set to free
parametrizable (in the physical unit of the in-
put) (S)
-103.00 to 103.00
zero_range_Xzu upper limit of zero range in % of X_100% (S)
-103.00 to 103.00
zero_range_Xzl lower limit of zero range in % of X_100% (S)
-103.00 to 103.00
zero_range_Yz Technological or normalized value of zero
range (S)
-1000000000000000.000 to
1000000000000000.000
zero_range_a MV_conv Zero range suppression (and check of the
plausibility limits) either standard or free
parametrizable (S)
• standard
• free configurable
OV_suppr_t OV suppression time in seconds, 0=no OV
suppression
0 to 255
