Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 143
DC8-001-2.09, Edition 08.2016
If for security reasons no connection between the networks may be established, the use of a
second IP address on interface X4 can be suppressed. Thereto, in the initial parameterization
can be defined whether the parameter Mode of ethernet ports is permanently displayed
or hidden.
This can be adjusted with the expert parameter Advanced parameters | Parameter |
“Mode of ethernet ports“ using the following selection:
• display (selection) (default)
• hide (freeze)
Note
With the selection hide (freeze) this parameter and the parameter Mode of ethernet ports are per-
manently hidden. A further change of these parameters is no longer possible!
The set mode remains unchanged, unless the target device will be restarted via a complete
reparameterization:
• Initialization with other parameters or with an anew generated SD card (SICAM TOOLBOX II).
• Initialization with an empty SD card (SICAM WEB).
• Store the changed settings by clicking
The stored values require a restart of the target device and are only active after the startup.
Note
After each change of the data, the target device can be accessed only by selection of the newly set IP ad-
dress(es).
If the access to the web server is no longer possible, check the IP settings of the engineering PC.
5.1.2.4.1 Access Options for the Engineering PC in Operation
DHCP service
used
DHCP server
available
Access option IP address
SICAM CMIC
IP address engineering
PC
Autoconfigu-
ration = NO
Irrelevant Ethernet (X1)
Own IP address
= <set value>
<free address in subnet of
SICAM CMIC>
Autoconfigu-
ration = YES
Yes Ethernet (X1)
Own IP address
= <automatic>
assigned by DHCP-
server, if DHCP is ena-
bled on the PC
Autoconfigu-
ration = YES
No Ethernet (X1)
Own IP address
= <169.254.0.1>
<free address in subnet
169.254.0>
(IP address in
SICAM CMIC is not rout-
ed)
Irrelevant Irrelevant
Ethernet (X4)
Own IP address
(X4) = <set value>
<free address in subnet of
SICAM CMIC>
*)
Irrelevant Irrelevant
Point-to-Point
(X2)
172.16.0.1 172.16.0.2 (assigned by
SICAM CMIC)
*)
applies only if Mode of the Ethernet ports = 2 IP addresses (independent ports)
