Siemens SICAM CMIC User Manual

Installation
38 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
1.4.1.2 Multi-Point Traffic via Glass Fibre Optic and Star Connection
Order information for the transmission facility and cables see SICAM CMIC System Descrip-
tion, Appendix “Order Information“, section “Accessories“.
1.4.1.3 Dial-up Traffic Analog with Westermo TD-36 and External Supply
Order information for the transmission facility and cables see SICAM CMIC System Descrip-
tion, Appendix “Order Information“, section “Accessories“.
F4
F3
F2
F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
CM-0827
PS-663x
CM-0822
Modular coupler
RJ45 9-pole D-SUB
Glass fibre optic cable
max. 1.5 km
F4F3F2F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
4
WE STERM O TD- 36
P
S
T
N
POWER
max. 2,5 m
Westermo TD-36
20...264 VAC / 14...300 VDC (TD-36 AV)
10...30 VAC / 10...60 VDC (TD-36 LV)
Power
supply
