Engineering via SICAM TOOLBOX II
SICAM RTUs, User Manual SICAM CMIC 123
DC8-001-2.09, Edition 08.2016
4.2.1.2 Configuring External Signals
The I/O’s are integrated into the Function Diagram via the Signal List. Dependent from the
fact, whether the target device is engineered via the SICAM TOOLBOX II or via the
SICAM WEB, the Signal List can be alternatively
• generated with the tool “OPM II”
• imported from a local parameterization (see thereto section 4.1.7, Import, Export and
Backup of Engineering Data)
The signals of the process-technical plant can be used by “CAEx plus” after the transformation
(see section 4.1.6, Transform Parameters). The structure of the project tree automatically
adapts to the structure from the “OPM II”.
An introduction how to create a project can be found in the CAEx plus Online Help, chapter
“First Steps” and chapter “Additional Products”, section “Signal List (Optional)”.
4.2.1.3 Tool CAEx plus
The tool “CAEx plus” provides various editors and standard libraries for the creation of the
open-/closed-loop control function.
The process-technical functions of a plant are created with the function diagram editor (FBD
Editor). A function diagram is thereby created by the interconnection of
• predefined functions and function blocks (SICAM CMIC library)
• functions and function blocks defined by the user
You find the description of the editor in the CAEx plus Online Help, chapter “Editors”.
Additional information can be found in the SICAM TOOLBOX II Online Help, chapter “Tutori-
als”, section “CAEx plus”.
You find the most important characteristic values (limits) for the creation of the open-/closed-
loop control function in the SICAM CMIC System Description, chapter “Technical Specifications
of the Modules”, section “Master Control Modules”.
You find the technical details for the processing of the open-/closed-loop control function and its
partial functions in the manual SICAM RTUs Common Functions System and Basic System
Elements, chapter “Automation”, section “Restricted Open-/Closed-Loop Control Function”,
“Application Program”,”Function Diagram”.
Note
Optionally to the creation of a function diagram, an instruction list (IL) with ASCII format can be imported in
“CAEx plus” (tool “OPM II”, context menu of the CPU, Instruction list | Import from file ).
