Service
298 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
6.3.2.3 System Performance
Information on the system performance of a selected automation unit can be interrogated with
the tool "Maintenance Function Online":
• Display equipped system elements
• Read serial numbers
• Display/delete data flow routing
• Shut down selected system elements
• Shut down selected automation unit
• Startup selected system elements
• Startup automation unit
• Display time
• Memory check
• Data processing capacity
• Control- and bus runtime
You find further details on the maintenance functions in the SICAM TOOLBOX II Online Help,
chapter "Maintenance Function Online".
6.3.2.4 Diagnosis of the Open-/Closed-Loop Control Function
With the tool "CAEx plus" the following status information can be displayed for each task with
the function ONLINE Test :
• Parameterized cycle time
• Current runtime
• Minimum/maximum runtime
• Number of runtime time-outs
• Bus runtime
You find further information in the manual SICAM RTUs Common Functions System and
Basic System Elements, chapter "Automation", section "Open-/Closed-loop Control Function",
section "Display Status Information".
Errors that can occur with the creation of the function diagram (for example the linking of a bi-
nary signal to an analog input of a function) are displayed in a separate report window ("POU
error check"):
• Automatic upon incorrect input
• Manually with the function Early error detection (pop-up menu in the function diagram)
You find the exact details in the CAEx plus Online Help, chapter "Editors", section "FBD Edi-
tor", section "Operation in FBD Editor".
