B.1 Transfer an Input to a Signalling Output and to a Com-
mand Output
The first digital input of the master control element (with default address and type identification
I_030_002_000_000.VALUE) is loaded into the accumulator. In the next line the loaded
value is transferred to the outputs O_030_008_000_000.VALUE and
O_045_009_000_000.VALUE.
Changing the input type from single command to single message with the engineering tool
(webbrowser), the relay at the output D00 picks up when the input becomes logical 1. Other-
wise this output address will be sent to the communication because it is not existing within the
periphery. The default address of the command is D01.
PLC_RESET:
PLC_INIT:
PLC_START:
LD I_030_002_000_000.VALUE (*IN00 TI:30 IOA1:002 IOA2:000 IOA3:000*)
ST O_030_008_000_000.VALUE (*store at output as binary information*)
ST O_045_009_000_000.VALUE (*store at output as command*)
