Page #111 background image
Engineering via SICAM TOOLBOX II
SICAM RTUs, User Manual SICAM CMIC 111
DC8-001-2.09, Edition 08.2016
4.1.5.2 System-Technical Settings
The system-technical configuration of a target device resides in the window “System tech-
nique”. This can be opened via the menu Tools | System technique .
The parameter setting is carried out in the directory tree, respectively below the selected basic
system element:
Common settings
Time management
Communication protocols
Network settings
Topology
Dataflow filter
Periphery
Decentral archiving
4.1.5.2.1 Communication
The protocol is determined by configuring a protocol element suitable for the existing applica-
tion and its parameterization.
For security relevant informationen refer to the SICAM RTUs / SICAM TOOLBOX II – Admin-
istrator Security Manual.
4.1.5.2.2 Periphery
The peripheral functions are defined by means of configuring the peripheral element, the
I/O modules suitable for the present application, as well as their parameters.
Below the level of the Ax peripheral bus the configured peripheral element with the configurable
signals is displayed:
Hardware pins
Software data points
By means of the context menu of a hardware pin or software data point, selection Edit
image , you get directly to the process-technical settings of the respective signal.
