Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 181
DC8-001-2.09, Edition 08.2016
Category Parameter Meaning
Command_output_time For TI 160: 0...6200•50 ms, for TI 45, 46, 47:
• 0=no additional definition
• 1=short pulse duration
• 2=long pule duration
• 3=persistent output
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
Special application output Function
• OR conjunction, falling edge time delayed
• AND conjunction, falling edge time delayed
• OR conjunction, output as transients, falling
edge time delayed
• Message conversion
• OR conjunction, rising edge time delayed
Inversion NO/YES
Fail_behav_status Conjunction type
Time_delay Time delay n•100 ms
• 0 0 no delay
• 1 = 100 ms
• 255 = 25.5 s
Sonderfunktion AMIS Devicetype G23-520
AMIS_Telegrammtyp Schaltbefehl LSG
Verweilzeit_(in_Sekunden) 0…100000
Schaltgruppe_(65535_für_BC) 0…65535
Befehlsnummer
priority
• Low priority
• High priority
binary_input-/commandstate OFF/ON
Meldungsempfang_mit_GA
• änderungsüberwacht weitergeben
• immer weitergeben
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
