Engineering via SICAM WEB
180 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
Category Parameter Meaning
Time_tag Transfer with or without time tag
Function_group
address-conversion 0 = yes, 1 = no
Change_sign_of_measured_
values
New_CASDU1 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
New_CASDU2 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
New_IOA1 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
New_IOA2 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
New_IOA3 New address of the datapoint. The complete
address consists of new CASDU1, CASDU2,
IOA1, IOA2 and IOA3. New CASDU1 and
CASDU2 = 255 means no address-
conversion.
Selectivity Selective or to all remote stations
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
Special application input OUT_CASDU1 Address of the datapoint
OUT_CASDU2 Address of the datapoint
OUT_IOA1 Address of the datapoint
OUT_IOA2 Address of the datapoint
OUT_IOA3 Address of the datapoint
OUT_TI Type identification according to
IEC 60870-5-101/104
Inversion NO/YES
TI31_Selection OFF/ON
Fail_behav Failure behavior
Fail_subst_value Substitute value at failure
single_object_number
Command_state
• Command state not evaluate
• Command state ON before OFF
• Command state OFF before ON
