Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
SICAM RTUs, User Manual SICAM CMIC 179
DC8-001-2.09, Edition 08.2016
Category Parameter Meaning
Station
• 0…99 = station number
• 125 = to all stations
• 255 = not used
Additional_parameter_(PRE) 0...65535 = meaning for each function de-
fined by the PRE firmware
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
104-Address
TI Type identification according to
IEC 60870-5-101/104
• Single-point information
• Single command
Protocol element return
information message
Return_information_function_
(PRE)
PRE_(RM) Protocol element number (0…3)
Station Station number (selective 0...99; to all sta-
tions; station not used)
Redundancy control
message
Control_function_(RED)
• User priority
• A/P-control
• Key switch
• Listening mode-control
• A/P-control with failed SCA-RS
• Switch-over disabled
Failure_behavior_(RED)
• Terminate binary information
• Maintain status
BSE_(RED) Basic system element
PRE_(RED) Protocol element number
Priority_(RED) Priority 0 (lowest)…priority 14 (highest)
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
Redundancy return in-
formation message
Return_information_function_
(RED)
• Redundancy state
• Switchover runs at a global switchover
• Keyswitch of the SCA-RS: system A active
• Keyswitch of the SCA-RS: automatic
• Keyswitch of the SCA-RS: system B active
• Listening mode
BSE_(RED) Basic system element
PRE_(RED) Protocol element number
Selective data flow rout-
ing
PRE Protocol element number (0…3)
Station 0…99 = selective station
unused = single-point-PRE or multi-point-
PRE to all remote stations
Data_class
• Data class 1
• Data class 2
Periodical transfer Selection periodical level or no periodical
transfer
Event_data
