Category Parameter Meaning
pva_X_100% Value adaptation: Upper limit of the used
measuring range in the external (protocol
specific) format. The corresponding internal
value is defined at Y_100%.
pva_Y_0% Value adaptation: Lower limit of the used
measuring range in the selected internal for-
mat. The internal format is defined at TI (type
identification). The corresponding external
value is defined at X_0%.
pva_Y_100% Value adaptation: Upper limit of the used
measuring range in the selected internal for-
mat. The internal format is defined at TI (type
identification). The corresponding external
value is defined at X_100%.
pva_Decimal_places Count of decimal places (max. 7)
pva_Unit_text The value is displayed with this unit text
(max. 8 characters)
Process value digital pvd_Event The data point is displayed in the event list
pvd_Alarm The data point is displayed in the alarme list
pvd_Process_Text The data point is displayed with this name
(max. 13 characters)
pvd_State_TextOn The state ON for single or double point infor-
mation is displayed with this name (max.
6 characters)
pvd_State_TextOff The state OFF for single or double point in-
formation is displayed with this name (max.
6 characters)
pvd_State_TextFlt The state faulty position for double point in-
formation is displayed with this name (max.
6 characters)
pvd_State_TextInt The state intermediate position for double
point information is displayed with this name
(max. 6 characters)
pvd_Process_GroupNbr The data point is displayed in the cockpit in
this group (1…32)
pvd_Process_GroupPos The data point is displayed in the cockpit on
this position (1…255)
QID-BSE Source identification basic system element
QID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
QID-SSE Source identification supplementary system
element
Protocol element control
message
Control_function_(PRE)
• 0...239 = function defined by protocol ele-
ment
• 240 = GI request
• 241 = reserved
• 242 = control location
• 244 = CASDU selective GI request
• 245...255 = reserve for further BSE func-
tions
Edge_(PRE)
• Positive edge
• Negative edge
• State (0 = function, 1 = function + 1)
PRE_(CM) Protocol element number
• PRE0…PRE3
• distribute over multimaster function
