Engineering via SICAM WEB
150 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
This page shows an overview of the equipped system elements:
• Master control module (Master module)
• Peripheral module (I/O Master module)
─ I/O modules
• Protocol elements (PRE 0, PRE 1, PRE 2, PRE 3)
Note
The selection in the drop-down boxes contains only that system elements, whose firmware has already
been loaded into the master control element (with indication of the revision level).
By clicking you will leave the equipment program. Changes will not be saved, that
means, selected system elements will be rejected.
• In the respective drop down list, select the desired entry
• If you want to save the adjusted equipment, click
A restart request appears:
You have the possibility to abort the procedure.
• Confirm by clicking
The target device performs a restart, refer to Restart device.
During startup, the settings are stored on the SD card and the configuration pages for the se-
lected system elements are built in SICAM WEB.
