Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
202 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
Processing type Parameter Meaning
RS_Image Parameter works only with ACP 1703 platform
DO_SI – digital output –
single-point information
receive_format Source of datapoint
Fail_behav Behavior at failure
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
SID-SSE Source identification supplementary system
element
DO_SX – single-point
information and single
command output
receive_format Source of datapoint
Fail_behav Behavior at failure
• keep
• terminate
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254. If
automatic then the source ID will be learned.
SID-SSE Source identification supplementary system
element
select_execute_t Max. time between select and execute (in se-
conds). After this time a recent select com-
mand is necessary.
0 = no select command is expected (direct
command transmission)
0 to 6553.5
RS_Image_CASDU1 Address of corresponding return state infor-
mation (S)
0 to 255
RS_Image_CASDU2 Address of corresponding return state infor-
mation (S)
0 to 255
RS_Image_IOA1 Address of corresponding return state infor-
mation (S)
0 to 255
RS_Image_IOA2 Address of corresponding return state infor-
mation (S)
0 to 255
RS_Image_IOA3 Address of corresponding return state infor-
mation (S)
0 to 255
Term_with_Conf Sending of termination immediately after
sending of confirmation (S)
NO/YES
Output_t Command output time in seconds (S).
Attention: The time comes into effect only, if in
the message is not defined any time.
0.01 to 327.67
termination_t Time between confirmation and termination (s)
0 = no termination
0 to 6553.5
RS_react_t Information reaction time (S)
Pulse command: 0 .. time appropriate to out-
put time
Persisitent command: 0 .. time appropriate to
termination time
0 to 6553.5
