Siemens SICAM CMIC User Manual

Engineering via SICAM WEB
206 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
Processing type Parameter Meaning
OV_suppr_t OV suppression time in seconds, 0=no OV
suppression
0 to 255
standard load The measuring range can be adapted with
changing the load (S)
NO/YES
SW_COSPHI - software
power factor
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
SW_CT_FDIR_I>_I>> I> Trip value in ampere for overcurrent detection
for short circuit 0: function disabled
50 to 2000
I>> Trip value in ampere for overcurrent detection
for short circuit 0: function disabled
50 to 2000
I>>_t Time delay for overcurrent detection
0.04 to 60
I>_t Time delay for overcurrent detection
0.04 to 60
t_reset Auto reset time
0 = function disabled
SW_CT_FDIR_IN IN> Trip value in ampere for ground fault 0: func-
tion disabled
0.4 to 2000
IN>_Idir Earth current for earth fault detection using
the wattmetric method 0: function disabled
0.2 to 30
IN>_ground_type Ground point treatment method
• solid
• isolated
• resonant
IN>_U0 Ground point displacement voltage in procent
of primary voltage 0: function disabled
0 to 100
IN>_U0_t Ground point displacement voltage time delay
0.04 to 60
IN>_t Time delay for ground fault indication
0.04 to 60
t_reset Auto reset time
0 = function disabled
SW_CT_MV_SELECTIO
N
measured_value_selection Selection of a measured value
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
thresh_uncond Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 103.00
SW_CT_PDIR –
SW_F – software fre-
quency
thresh_additive Change threshold in % of X_100% (S) AI_T:
% of temperature range
0 to 1000.0
