Engineering via SICAM WEB
208 SICAM RTUs, User Manual SICAM CMIC
DC8-001-2.09, Edition 08.2016
Processing type Parameter Meaning
transformer_X_100% Nominal range of transformer/input: second-
ary
• 8510: 100 V/SQRT3 - 8511: 3.25 V/SQRT3
• 8510: 230 V - 8511: 3.25 V/SQRT3
• 8510: 400 V/SQRT3 - 8511: 3.25 V/SQRT3
transformer_Y_100% Nominal range of transformer: primary in kV
or 230 V or in Ampere
1.0 to 36.0
transformer_type Transformer type
transformer_angle Angle between upper and lower side of trans-
former
0 to 359
Overrange Definition of the overrange for QDS 'OV' in %
of the nominal range of the transformer
