Installation
SICAM RTUs, User Manual SICAM CMIC 33
DC8-001-2.09, Edition 08.2016
Caution
To increase the stability it is necessary to mount an end clamp
flush left from the SICAM CMIC device and
flush right after the last SICAM I/O module.
You can take information on the SICAM I/O modules out of the following documents:
Document name Item number
SICAM I/O Modules DC8-012-2
Please consider also the notes in the SICAM CMIC System Description, chapter “System
Overview”, section “Architecture” | “I/O Modules” | “External I/O Modules” | “Configuration
Notes”.
SICAM CMIC
F4F3F2F1
SICAM CMIC
POK
RY
ER
E TH
LK1
PK1
R S - 232
OH2
RTX2
R S - 485
OH3
RTX3
E TH
LK4
PK4
SD
X4
RY RY
RY RY
