Siemens SICAM CMIC User Manual

Interfaces and Circuitry
SICAM RTUs, User Manual SICAM CMIC 51
DC8-001-2.09, Edition 08.2016
Communication interfaces on the front
SD card X4: Ethernet
TXD
+
TXD
-
RXD+
n
ot used
n
ot used
RXD
-
n
ot used
n
ot used
1 2 3 4 5 6 7 8
The abbreviations have the following meaning:
TXD+……………… Transmit Data +
TXD-………………. Transmit Data -
RXD+……………… Receive Data +
RXD-………………. Receive Data -
Interfaces on the bottom
The process signals are to be connected to screw terminals. The pin assignment of the pe-
ripheral connectors is described in the following table.
X31 X32 X33 DI-8100
IN D00
IN D01
IN D02
IN D03
IN D04
IN D05
IN D06
IN D07
COM IN 00
IN D10
IN D11
IN D12
IN D13
COM IN 10
reserved
reserved
reserved
reserved
1 2 3 4 5 6 7 8 9 1 2 3 4 5 1 2 3 4
X21 X22 X23 X24 DO-8203
OUT D00
OUT D01
COM OUT D00
COM OUT D01
OUT D02
OUT D03
COM OUT D02
COM OUT D03
OUT D04
OUT D05
COM OUT D04
COM OUT D05
OUT D06
OUT D07
COM OUT D06
COM OUT D07
1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4
X11 X12 X13 X14 PS-8630
reserved
reserved
reserved
reserved
reserved
BAT+
BAT
-
AUX V0+
AUX V0+
AUX V0+
AUX V0
-
AUX V0
-
reserved
reserved
1 2 3 1 2 3 4 1 2 3 4 5 1 2
The abbreviations have the following meaning:
IN D00 to IN D07…………… binary inputs of group 0, inputs 0 to 7
IN D10 to IN D13…………… binary inputs of group 1, inputs 10 to 13
COM IN 00…………………… common/supply of group 0
COM IN 10…………………… common/supply of group 1
OUT D00 to D07…………… make contact outputs 0 to 7
COM OUT D00 to D07…….. common (root) outputs 0 to 7
BAT+/-………………………… input voltage
AUX V0+/-……………………. voltage distribution
