215Basic Procedure for Wipe Settings
Chapter 5 Wipes
You can set the position independently for the main pattern and sub pattern.
1
In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
In the <Position> group, press [Position], turning it on, and set the pattern
position.
To return the pattern position to the center of the screen
In the <Position> group, press [Center].
To move the pattern from its current position to the center through
the course of a transition
In the <Position> group, press [Auto Center], turning it on.
To set the wipe position using the trackball
You can also set the wipe position using the trackball in the device control
block.
1
In the device control block, press the [M/E1] or [P/P] button, turning it on.
The buttons in the device control block are assigned to the wipe position
setting as follows.
2
Press the [MAIN] button or [SUB] button, turning it on.
3
Press the [POS] button, turning Position on.
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–200.00 to +200.00
2 Position V Vertical position
–200.00 to +200.00
Table 1: Buttons and assigned settings
Button name Setting
MAIN Wipe position for common transition (main pattern)
SUB Wipe position for common transition (sub pattern)
Table 2: Buttons assigned to functions
Button name Function
POS Toggle Position on or off.
X, Y Fix the operating direction.
CTR Return the pattern position to the center of the screen.
